1SCREEN 13
2
3CONST CNT = 3
4
5' Stack for current situation
6DIM SHARED W(0 TO 15, 0 TO 2) AS INTEGER
7
8' Draw plates & column
9FOR i = 0 TO 2: LINE (50 + i * 100 - 1, 25)-(50 + i * 100 + 1, 184), 6, BF: NEXT
10FOR i = 0 TO 15: W(i, 0) = -1: W(i, 1) = -1: W(i, 2) = -1: NEXT
11FOR i = 0 TO CNT - 1: DrawPlate 0, i, i: W(i, 0) = i: NEXT
12
13' Solve task
14Hanoi 0, 1, 2, CNT
15
16SLEEP 0
17
18SUB Delay (N)
19  FOR i = 0 TO N * 100: NEXT
20  N = N * .99
21END SUB
22
23SUB DrawPlate (col, row, isize)
24
25  x = 50 + 100 * col
26  y = 170 - row * 11
27  cl = 1 + isize
28  size = 45 - isize * 5
29
30  LINE (x - size, y)-(x + size, y + 10), cl, BF
31  LINE (x - size, y)-(x + size, y + 10), 15, B
32  LINE (x - size, y + 10)-(x + size, y + 10), 8
33  LINE (x + size, y + 10)-(x + size, y), 8
34
35END SUB
36
37SUB Hanoi (A, B, C, N)
38
39  ' Front
40  IF N > 1 THEN Hanoi A, C, B, N - 1
41
42  ' Get from A and place to B
43  FOR i = 0 TO CNT
44    IF W(i, A) = -1 THEN irow = i: cl = W(i - 1, A): EXIT FOR
45  NEXT
46
47  FOR i = 0 TO CNT
48    IF W(i, B) = -1 THEN orow = i: EXIT FOR
49  NEXT
50
51  ' Move plate
52  W(orow, B) = W(irow - 1, A)
53  W(irow - 1, A) = -1
54
55  ' Animate
56  Move A, irow - 1, cl, B, orow
57
58  ' Back
59  IF N > 1 THEN Hanoi C, B, A, N - 1
60
61END SUB
62
63' From column, row, size (color) -> column, row
64SUB Move (icol, irow, isize, ocol, orow)
65
66  DL = 25
67  HG = 170
68
69  ' Direction for move
70  IF icol < ocol THEN dir = 1 ELSE dir = -1
71
72  x = 50 + 100 * icol
73  y = HG - irow * 11
74  cl = 1 + isize
75  size = 45 - isize * 5
76
77  ' Count increments
78  icnt = y - 15
79  ocnt = HG - orow * 11 - 15
80
81  ' Incremental UP
82  FOR i = 0 TO icnt
83
84    ' Clear one line
85    LINE (x - size, y + 10)-(x - 2, y + 10), 0, BF
86    LINE (x - 1, y + 10)-(x + 1, y + 10), 6, BF
87    LINE (x + 2, y + 10)-(x + size, y + 10), 0, BF
88
89    ' Draw underline
90    LINE (x - size, y + 9)-(x + size, y + 9), 8
91    LINE (x - size + 1, y)-(x + size - 1, y), cl
92    LINE (x - size, y - 1)-(x + size, y - 1), 15
93    PSET (x + size, y), 8
94
95    y = y - 1
96    Delay DL
97
98  NEXT
99
100  ' Move right/left
101  xl = x - size
102  xr = x + size
103  FOR i = 0 TO 100 * ABS(icol - ocol) - 1
104
105    ' Move RIGHT
106    IF dir > 0 THEN
107
108      LINE (xl, y)-(xl, y + 10), 0
109      LINE (xl + 1, y)-(xl + 1, y + 10), 15
110      LINE (xr, y)-(xr, y + 10), cl
111      PSET (xr, y), 15
112      PSET (xr, y + 10), 8
113      LINE (xr + 1, y)-(xr + 1, y + 10), 8
114      xl = xl + 1
115      xr = xr + 1
116      Delay DL
117
118    ELSE
119
120      LINE (xr, y)-(xr, y + 10), 0
121      LINE (xr - 1, y)-(xr - 1, y + 10), 15
122      LINE (xl, y)-(xl, y + 10), cl
123      PSET (xl, y), 15
124      PSET (xl, y + 10), 8
125      LINE (xl - 1, y)-(xl - 1, y + 10), 8
126      xl = xl - 1
127      xr = xr - 1
128      Delay DL
129
130    END IF
131
132  NEXT
133
134  ' Incremental DOWN
135  FOR i = 0 TO ocnt
136
137    LINE (xl, y)-(xr, y), 0
138    LINE (xl + 1, y + 10)-(xr - 1, y + 10), cl
139    LINE (xl, y + 1)-(xr, y + 1), 15
140    PSET (xl, y + 10), 15
141    LINE (xl, y + 11)-(xr, y + 11), 8
142
143    ' Draw if real column
144    IF i > 10 THEN LINE (xl + size - 1, y)-(xr - size + 1, y), 6
145
146    y = y + 1
147    Delay DL
148
149  NEXT
150
151END SUB
